INFORMATIONS GÉNÉRALES |
Marque | | Gigabyte |
Référence fabricant (SKU) | | A620M GAMING X AX |
Modèle | | A620M GAMING X AX mATX AM5 DDR5 WIFI |
PROCESSEUR |
Compatibilité CPU | | AMD Ryzen™ 7000 Series Processors |
Socket | | AMD AM5 |
CHIPSET |
Chipset | | AMD A620 |
MÉMOIRE |
Type | | DDR5 |
Fréquences mémoire | | 6400(OC) / 6200(OC) / 6000(OC) / 5600(OC) / 5200 / 4800 / 4400 MT/s |
Technologie Dual Channel | | Oui |
Capacité maximale par slot | | 48 Go |
Capacité maximale | | 192 Go |
RAM ECC prise en charge | | Non |
CHIPSET GRAPHIQUE EMBARQUÉ |
Chipset graphique embarqué | | 1 x DisplayPort, supportant une résolution maximale de 3840x2160@144 Hz * Support pour la version DisplayPort 1.4 1 x HDMI port, supportant une résolution maximale de 4096x2160@60 Hz * Support pour la version HDMI 2.1 et HDCP 2.3. ** Support natif pour les ports HDMI 2.1 compatibles |
Compatible avec le chipset graphique du CPU | | N/A |
AUDIO |
Chipset audio | | Realtek® Audio CODEC High Definition Audio |
Canaux | | 2/4/5.1/7.1 |
RÉSEAU |
Ethernet RJ45 | | Realtek® GbE LAN chip (1 Gbps/100 Mbps) |
WiFi | | Realtek® Wi-Fi 6E RTL8852CE |
Bluetooth | | BLUETOOTH 5.2 |
STOCKAGE |
Ports SATA | | 4 x SATA 6Gb/s |
Ports M.2 | | 1 x M.2 (Socket 3, M key, type 2580 PCIe 4.0 x4/x2 SSD support) |
Compatibilité RAID | | RAID 0, RAID 1, and RAID 10 support for SATA storage devices |
SOLTS D'EXTENSION |
PCI-Ex 16x | | 1 x PCI Express x16 slot, supportant le PCIe 4.0 |
PCI-Ex 8x | | 0 |
PCI-Ex 4x | | 0 |
PCI-Ex 1x | | 1 x PCI Express x1 slot, supportant le PCIe 3.0 |
CONNECTIQUES |
Panneau arrière | | 1 x PS/2 clavier/souris port 1 x USB Type-C® supportant USB 3.2 Gen 1 1 x USB 3.2 Gen 2 Type-A 2 x USB 3.2 Gen 1 2 x USB 2.0/1.1 1 x HDMI 1 x DisplayPort 1 x Bouton Q-Flash Plus 1 x RJ-45 3 x prises jack |
Ports USB | | 1 x USB Type-C® supportant USB 3.2 Gen 1 1 x USB 3.2 Gen 2 Type-A 2 x USB 3.2 Gen 1 2 x USB 2.0/1.1 |
Connecteurs supplémentaires | | 1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 1 x CPU fan header 2 x system fan headers 1 x addressable LED strip header 1 x RGB LED strip header 1 x M.2 Socket 3 connector 4 x SATA 6Gb/s connectors 1 x front panel header 1 x front panel audio header 1 x USB Type-C® header, with USB 3.2 Gen 1 support 1 x USB 3.2 Gen 1 header 1 x USB 2.0/1.1 header 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only) 1 x Clear CMOS jumper |
CARACTÉRISTIQUES PHYSIQUES |
Dimensions | | 244 x 244 mm |
Couleur | | Noir |
LED | | Non |
Format | | Micro ATX |
GARANTIE |
Garantie constructeur | | 36 mois |
