Compatibilité du Bus
Performances audio
- Output Signal-to-Noise Ratio (A-Weighted) (Front-out) : 110 dB
- Output Signal-to-Noise Ratio (A-Weighted) (Headphone-out) : 108 dB
- Input Signal-to-Noise Ratio (A-Weighted) : 103 dB
- Output THD+N at 1kHz (Front-out) : <0.00158 %(-96 dB)
- Input THD+N at 1kHz : <0.0022 %(-93 dB)
- Frequency Response (-3dB, 24bit/192KHz input) : 10 Hz to 65 KHz
Chipset
- Audio Processor :C-Media USB2.0 6632AE High-Definition Sound Processor (Max. 192KHz/24bit)
Convertisseur numérique vers analogique (DAC)
- ESS ES9023P*1 (112dB DNR, Max. 192KHz/24bit)
- Cirrus Logic CS4245*1 (104dB DNR, Max. 192KHz/24bit)
- Cirrus Logic CS4361*1 (103dB DNR, Max. 192KHz/24bit)
Résolution et taux d´échantillonnage
- Analog Playback Sample Rate and Resolution : 44.1K/48K/88.2K/96K/176.4K/192KHz @ 16bit/24bit
- Analog Recording Sample Rate and Resolution : 44.1K/48K/88.2K/96KHz @ 16bit/24bit
- S/PDIF Digital Output : 44.1K/48K/88.2K/96K/176.4K/192KHz @ 16bit/24bit
- ASIO 2.2 Driver Support : 44.1K/48K/96K/192KHz @ 24bit/32bit
Connectique
- Analog Output : 5 x 3.5 mm jack (1/8") (Headphone out /Front out/Side out/Center-Subwoofer out/Rear out)
- Analog Input : 1 x 3.5 mm jack (1/8") (Line-in/ Mic-in combo)
- Digital : 1 x S/PDIF out (1 x Optical (Toslink))
Fonctionnalités spécifiques
Système d´exploitation
- Windows® 10
- Windows® 8.1
- Windows® 7
- Please update your BIOS and drivers to the latest version to support Windows 7
Accessoires
- Quick start guide x 1
- Driver CD x 1
Pour plus d'informations, vous pouvez consulter la page du produit sur le site du constructeur, disponible ICI
Code EAN-13 : 4712900633603
Fiche technique
- Référence Fabricant
- 90YA00P0-M0UA00
- Utilisation type
- Gaming
- Garantie Constructeur (Mois)
- 12
