ROG SupremeFX 7.1-Channel High Definition Audio CODEC S1220A
Canaux
Jusqu'à 7.1
RÉSEAU
Ethernet RJ45
1 x Intel® 2.5Gb Ethernet
WiFi
Wi-Fi 6E 2x2 Wi-Fi 6E (802.11 a/b/g/n/ac/ax)
Bluetooth
Bluetooth 5.3
STOCKAGE
Ports SATA
4 x SATA 6Gb/s
Ports M.2
CPU : M.2_1 (Key M), type 2260/2280 (compatible PCIe 4.0 x4 mode) Chipset : M.2_2 (Key M), type 2242/2260/2280 (compatible PCIe 4.0 x4 mode)
Compatibilité RAID
Intel® Rapid Storage Technology compatible SATA RAID 0/1/5/10
SOLTS D'EXTENSION
PCI-Ex 16x
1 x PCIe 5.0 x16 slot
PCI-Ex 8x
Non
PCI-Ex 4x
Non
PCI-Ex 1x
Non
CONNECTIQUES
Panneau arrière
1 x USB 3.2 Gen 2x2 1 x USB Type-C® 4 x USB 3.2 Gen 1 (3 x Type-A +1 x USB Type-C®) 3 x USB 2.0 ports (3 x Type-A) 1 x HDMI® 1 x DisplayPort 1 x Wi-Fi Module 1 x Intel® 2.5Gb Ethernet 5 x Audio jacks
Ports USB
1 x USB 3.2 Gen 2 (compatible USB Type-C®) 1 x USB 3.2 Gen 1 (supporte 2 x USB 3.2 Gen 1 supplémentaires) 1 x USB 2.0 (supporte 2 x USB 2.0 supplémentaires)
Connecteurs supplémentaires
1 x 4-pin CPU Fan header 1 x 4-pin Chasis Fan header 1 x 4-pin AIO Pump header 1 x 24-pin Main Power connector 1 x 8-pin +12V Power connector 2 x M.2 slots (Key M) 4 x SATA 6Gb/s ports 1 x Addressable Gen 2 headers 1 x Aura RGB header 1 x Clear CMOS header 1 x Front Panel Audio header (AAFP) 1 x S/PDIF Out header 1 x Speaker header 1 x 10-1 pin System Panel header 1 x Thermal Sensor header
