ROG SupremeFX 7.1 Surround Sound High Definition Audio CODEC ALC4080
Canaux
Jusqu'à 7.1
RÉSEAU
Ethernet RJ45
1 x Intel® 2.5Gb Ethernet
WiFi
Wi-Fi 6E 2x2 Wi-Fi 6E (802.11 a/b/g/n/ac/ax)
Bluetooth
Bluetooth 5.3
STOCKAGE
Ports SATA
4 x SATA 6Gb/s
Ports M.2
CPU : M.2_1 (Key M), type 2242/2260/2280 compatible PCIe 4.0 x4 mode Chipset : M.2_2 (Key M), type 2242/2260/2280/22110 compatible PCIe 4.0 x4 M.2_3 (Key M), type 2242/2260/2280 compatible PCIe 4.0 x4
Compatibilité RAID
Intel® Rapid Storage Technology compatible SATA RAID 0/1/5/10
SOLTS D'EXTENSION
PCI-Ex 16x
1 x PCIe 5.0x16 slot (supports x16 mode)
PCI-Ex 8x
PCI-Ex 4x
1 x PCIe 3.0 x16 slot (supports x4 mode)
PCI-Ex 1x
2 x PCIe 3.0 x1 slots
CONNECTIQUES
Panneau arrière
1 x USB 3.2 Gen 2x2 (1 x USB Type-C®) 1 x USB 3.2 Gen 2 (1 x Type-A) 6 x USB 3.2 Gen 1 (6 x Type-A) 1 x DisplayPort 1 x HDMI® 1 x Wi-Fi Module 1 x Intel® 2.5Gb Ethernet port 5 x Audio jacks 1 x Sortie optique S/PDIF 1 x Bouton BIOS FlashBack™ 1 x Bouton Clear CMOS
Ports USB
1 x USB 3.2 Gen 2 (compatible USB Type-C® ) 1 x USB 3.2 Gen 1 (supporte 2 x USB 3.2 Gen 1 supplémentaires) 2 x USB 2.0 (supporte 4 x USB 2.0 supplémentaires)
Connecteurs supplémentaires
1 x 4-pin CPU Fan header 1 x 4-pin CPU OPT Fan header 1 x 4-pin AIO Pump header 4 x 4-pin Chassis Fan headers 1 x 24-pin Main Power connector 1 x 8-pin +12V Power connector 1 x 4-pin +12V Power connector 3 x M.2 slots (Key M) 4 x SATA 6Gb/s ports 3 x Addressable Gen 2 headers 1 x Aura RGB header 1 x Front Panel Audio header (AAFP) 1 x 20-3 pin System Panel header with Chassis intrude function 1 x Thermal Sensor header 1 xThunderbolt™ (USB4®) header
