- Model Number
- MCB-NR200P-KGNN-S00, MCB-NR200P-WGNN-S00
- Series
- MasterBox Series
- Size
- Mini ITX
- Available Color(s)
- Black, White
- Materials
- Steel, Plastic, Mesh, Tempered Glass
- Dimensions (L x W x H)
- 376 x 185 x 292mm incl. Protrusions, 360 x 185 x 274mm excl. Protrusions
- Volume (exlc. Protrusions)
- 18.25L
- Motherboard Support
- Mini DTX, Mini ITX, Max. size: 244 x 226mm
- Expansion Slots
- 3
- 5.25" Drive Bays
- 0
- 3.5" Drive Bays
- 1 (Max. 2)
- 2.5" / 3.5" Drive Bays (combo)
- 1
- 2.5" Drive Bays
- 2 (Max. 3)
- I/O Panel
- 2x USB 3.2 Gen 1 Type-A, 1x 3.5mm Headset Jack (Audio+Mic)
- Pre-installed Fans - Top
- 2x 120mm 650-1800RPM PWM (SickleFlow)
- Pre-installed Fans - Front
- N/A
- Pre-installed Fans - Rear
- N/A
- Pre-installed Fans - Bottom
- N/A
- Fan Support - Top
- 2x 120mm
- Fan Support - Rear
- 1x 92mm
- Fan Support - Bottom
- 2x 120mm (recommended slim fans for GPUs wider than 2.5 PCI slots)
- Fan Support - Side
- 2x 120/140mm
- Radiator Support - Top
- N/A
- Radiator Support - Rear
- 92mm (not compatible with vertical GPU installation)
- Radiator Support - Bottom
- 120mm, 240mm, (recommended only for single slot water-cooled GPUs or vertically mounted GPUs)
- Radiator Support - Side
- 120mm, 140mm, 240mm, 280mm, (not compatible with vertical GPU installation)
- Clearance - CPU Cooler
- 76mm (GPU in vertical position), 153mm (tempered glass side panel), 155mm (vented steel side panel)
- Clearance - PSU
- 130mm
- Clearance - GFX
- L: 330mm (incl. power connector), H: 156mm (incl. power connector), W: 60mm (triple slot)
- Dust Filters
- Top, Bottom, Left side, Right side
- Power Supply Support
- SFX, SFX-L
- Warranty
- 2 years
- EAN Code
- 4719512106761 (MCB-NR200P-KGNN-S00), 4719512106778 (MCB-NR200P-WGNN-S00)
- UPC Code
- 884102079078 (MCB-NR200P-KGNN-S00), 884102079085 (MCB-NR200P-WGNN-S00)
- Weight
- 5.1 kg
- Accessories
- 1x PCIe 3.0 x16 riser cable
- Pour plus d'informations, vous pouvez consulter la page du produit sur le site du constructeur, disponible ICI
Code EAN-13 : 4719512106761
Fiche technique
- Référence Fabricant
- MCB-NR200P-KGNN-S00
- Format Carte Mère
- Mini ITX
- Utilisation type
- Gaming
- Couleur
- Noir
- LED RGB
- Non
- Dimensions (LxPxH)
- 376 x 185 x 292 mm
- Longueur max. Carte Graphique
- 330 mm
- Hauteur max. du Ventilateur CPU
- 153 mm
- Compatibilité Watercooling
- 120 - 240 - 280
- Format Alimentation
- SFX
- Garantie Constructeur (Mois)
- 24
- Refroidissement CPU
- #RCPU:120,240,280,Air
