Performances |
|---|
| Capacité de commutation | 32Gbps |
|---|
| Taux de transfert de paquets | 23.8Mbps |
|---|
| Tableau d'adresses MAC | 8K |
|---|
| Mémoire tampon des paquets | 4.1Mbit |
|---|
| Trame Géante | 9KB |
|---|
CARACTERISTIQUES LOGICIELLES |
|---|
| Qualité de Service QoS | Support Port-Based/802.1p/DSCP priority
Support 4 priority queues
Rate Limit
Storm Control |
|---|
| Fonctions N2 | IGMP Snooping V1/V2/V3
Link Aggregation
Port Mirroring
Cable Diagnostics
Loop Prevention |
|---|
| VLAN | Supports up to 128 VLANs simultaneously (out of 4K VLAN IDs)
MTU/Port/Tag VLAN |
|---|
| Administration | Web-based GUI
Easy Smart Configuration Utility |
|---|
| Méthode de transmission | Store-And-Forward |
|---|
AUTRES |
|---|
| Certification | FCC, CE, RoHS |
|---|
| Contenu de l'emballage | TL-SG1016PE
Power Cord
Installation Guide
Resource CD
Rackmount Kit
Rubber Feet |
|---|
| Système requis | Microsoft® Windows® for running Utility |
|---|
| Environnement | Operating Temperature: 0℃~40℃
Storage Temperature: -40℃~70℃
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing |
|---|
CARACTERISTIQUES MATERIELLES |
|---|
| Standards et Protocoles | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.1q, IEEE 802.1p |
|---|
| Interface | 16 10/100/1000Mbps RJ45 Ports
AUTO Negotiation/AUTO MDI/MDIX |
|---|
| Interface réseau | 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
100BASE-TX: UTP category 5, 5e cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m) |
|---|
| Nombre de ventilateurs | 1 |
|---|
| Système de verrou physique | Yes |
|---|
| Ports PoE (RJ45) | Standard: 802.3 at compliant
PoE Ports: Port 1- Port 8
PoE Power Budget: 110W |
|---|
| Dimensions (LxPxH) | 294*180*44 mm |
|---|
| Montage | Rack Mountable |
|---|
| Consommation maximale | 14.72W (110V/60Hz with no PD connected)
131.42W (110V/60Hz with 110W PD connected) |
|---|
| Max dissipation thermique | 50.22 BTU/h (with no PD connected)
448.41 BTU/h (with 110W PD connected) |
|---|
Code EAN-13 : 6935364098865
Fiche technique
- Référence Fabricant
- TL-SG1016PE
- Dimensions (LxPxH)
- 29.4 x 18 x 4.4 cm
- Garantie Constructeur (Mois)
- 36
